Description
Features:
1.Color touch screen, man-machine interface control, comvenient and quick parameter setting. easier data operatior
and material jams:
2.Adopt high-precision guide rail, servo motor and PLC control system to achieve high processing precision. high efficiency
and automation:
3. The punching pressure and clamp pressure are adjustable, suitable for punching various pipes with different thicknesses,
and can choose half hole or full hole. The oil cylinder has the characteristics of high-speed descent, low-speed punching,
and high-speed return, which reasonably reduces the working load of the motor and effe
4. The use of professionally made mold steel materials, casing bearing guide, effectively protect the mold, enhance the life,
make the workpiece punching smoothly,without burrs,scratches,and,materaljams;
5.The cylinder has the characteristics of height drop, low speed drop and high speed return, which reasonably reduces the
working load of the motor and achieves the effect of energy saving.
Application
Machining Application: Non-standard CNC machine tool, metal forming CNC machine tool
Motion Method: Point-to-point control
Control Method: Semi-closed-loop control
Performance Level: High-end CNC machine tool
Condition: Brand new
Out-of-warranty Services: Video technical support, spare parts, maintenance
Weight (tons): 1.5 tons
Color: Blue and yellow two-tone
Material: Steel
CNC Machining Required: Yes
Machine Tool Test Report: Provided
System: Servo
Origin: China
Motor Power (kW): 18.5 kW
Main Selling Point: Multifunctional
Applicable Industries: Stainless steel, sheet metal, plastics, aluminum alloys
Market Type: Other
Video Factory Inspection: Provided
Core Components: Motor, oil, pump, system, solenoid valve
Rebound Force (kN): 30 kN
Dimensions: 800*1600*7300
Trademark: tigertikant
Origin: Guangdong, China
Annual Production Capacity: 5000 units/year
Motion Method: Point-to-point control
Control Method: Semi-closed-loop control
Performance Level: High-end CNC machine tool
Condition: Brand new
Out-of-warranty Services: Video technical support, spare parts, maintenance
Weight (tons): 1.5 tons
Color: Blue and yellow two-tone
Material: Steel
CNC Machining Required: Yes
Machine Tool Test Report: Provided
System: Servo
Origin: China
Motor Power (kW): 18.5 kW
Main Selling Point: Multifunctional
Applicable Industries: Stainless steel, sheet metal, plastics, aluminum alloys
Market Type: Other
Video Factory Inspection: Provided
Core Components: Motor, oil, pump, system, solenoid valve
Rebound Force (kN): 30 kN
Dimensions: 800*1600*7300
Trademark: tigertikant
Origin: Guangdong, China
Annual Production Capacity: 5000 units/year
Product Description
Features:
1.Color touch screen, man-machine interface control, comvenient and quick parameter setting. easier data operatior
and material jams:
2.Adopt high-precision guide rail, servo motor and PLC control system to achieve high processing precision. high efficiency
and automation:
3. The punching pressure and clamp pressure are adjustable, suitable for punching various pipes with different thicknesses,
and can choose half hole or full hole. The oil cylinder has the characteristics of high-speed descent, low-speed punching,
and high-speed return, which reasonably reduces the working load of the motor and effe
4. The use of professionally made mold steel materials, casing bearing guide, effectively protect the mold, enhance the life,
make the workpiece punching smoothly,without burrs,scratches,and,materaljams;
5.The cylinder has the characteristics of height drop, low speed drop and high speed return, which reasonably reduces the
working load of the motor and achieves the effect of energy saving.
|
Technical parameters: |
BG-SKDL-01 | BG-SKDL-02 | BG-SKDL-03 |
| Product size: | 800*1600*7300mm | 900*1600*7300mm | 1000*1600*7300mm |
| Main motor efficiency: | 7.5KW | 11KW | 18.5KW |
| Servo Motor Power: | 0.75KW/1.0KW | 1.0KW/1.5KW | 1.5KW/2.0KW |
| Length Range: | ≤6000mm | ≤6000mm | ≤6000mm |
| Punching Force: | 80Kn | 80Kn | 80Kn |
| Greatest Pressure: | 16mpa | 16mpa | 16mpa |
| Punching Frequency: | 0.3-1.5s/second | 0.3-1.5s/second | 0.3-1.5s/second |
| Oil Pump Displacement | 31discharge volume | 31discharge volume | 31discharge volume |
| Feeding Method: | PLC System control | PLC System control | PLC System control |
| Control System: | Cylinder clamping material, servo drive feeding | Cylinder clamping material, servo drive feeding | Cylinder clamping material, servo drive feeding |
| Cooling Method: | Forced cold air 150L | Forced cold air 150L | Forced cold air 150L |
| The Electromagnetic | DSG-03-3C6-DL | DSG-03-3C6-DL | DSG-03-3C6-DL |
| Reducer: | 1:10Planetary reducer | 1:10Planetary reducer | 1:10Planetary reducer |
| Net Weight: | 1.5T | 1.5T | 1.5T |
| Cylinder Size: | Cylinder size can be matched according to customer requirements(80,100,125,140,180Cylinder)Can be customized non-standard pipe, plate stamping automatic equipment | ||
| Appropriate Types: | Round, square, rectangular, elliptical, steel tubing in different shapes, steel groove, I-section, T-section, etc. | ||
